InstrumentOverview21
Figure 1‐9ConnectingtheDCpowerplug
ThepowerstatusoftheACcharger/adaptorandthebatterychargeconditionare
indicatedbothonthefrontpaneloftheEPOCH 600,aswellasintheuserinterface
(seeTable 2onpage 21).
Table 2ACcharger/adaptorpowerindicatorstatus
Power
indicator
status
AClinepower
connected
Indicatormeaning
Battery
indicator
Green Yes Internalbatteryfullycharged
Red Yes Internalbatteryischarging
Off No ACcharger/adaptornotconnected
DC power plug
DC adaptor
connector (rubber
seal not shown)
