DMTA041-01EN [U8778479], Rev. C, May 2014
Chapter 2
26
Figure 2-1 The TomoScan FOCUS LT instrument
To install the TomoScan FOCUS LT instrument
Install the TomoScan FOCUS LT away from heat sources, leaving a minimum
clearance of 5 cm (2 in.) to allow for heat dissipation.
Do not leave the TomoScan FOCUS LT vertical on the bumpers of the back panel,
because the high center of gravity could make it unstable and likely to fall over.
Moreover, the insufficient clearance of the fans would impede proper cooling.
The TomoScan FOCUS LT must be properly ventilated to prevent overheating and to
ensure an appropriate operation. Be sure to use the instrument in a well-ventilated
area while avoiding the obstruction of the air inlets located on the front panel of the
enclosure as well as the air outlets located on both sides of the housing.
