DMTA041-01EN [U8778479], Rev. C, May 2014
Chapter 2
28
Olympus strongly recommends turning off the TomoScan FOCUS LT instrument
before connecting and disconnecting the probes.
5. Using the appropriate cables, connect each of the components required by your
setup and your needs to the corresponding TomoScan FOCUS LT connector (for
example, encoders, alarms, etc.). For all the details on the connectors, see “Back
Panel Description” on page 20.
6. When using an AC power source, connect the power cord to the power entry
module of the TomoScan FOCUS LT back panel. Connect the other end of the
power cord to a three-terminal-grounded power outlet. Turn on the TomoScan
FOCUS LT by pressing the front panel on/off switch.
7. When using a DC power source, connect the power cord to the
DC IN connector of
the TomoScan FOCUS LT front panel. Connect the other end of the power cord to
a suitable DC power source. Turn on the TomoScan FOCUS LT by pressing the
front panel on/off switch.
2.4 Probe Connection
• In phased array mode, probes are connected to the UT PHASED ARRAY connector.
• In conventional ultrasound mode, probes are connected to the
P125 to P128
connectors.
Olympus strongly recommends turning off the TomoScan FOCUS LT before
connecting and disconnecting the probes.
Probes can suffer permanent damage if fired without couplant for more than one
hour. If the probes are not being used for inspection, the TomoScan FOCUS LT
instrument should be turned off.
