Olympus TomoScan FOCUS LT - DC out Connector; Figure 6-2 the Trig on Dout 2 for a Signal of 50 R

DMTA041-01EN [U8778479], Rev. C, May 2014
Chapter 6 62
If the required DIN signal is greater than 50 µs, then maximum PRF will be lower
than 10 kHz.
Figure 6-2 The Trig on Dout 2 for a signal of 50R
6.2 DC OUT Connector
Description
5-pin, female connector
Manufacturer; number
LEMO; HGG.2B.305.CLLP
Olympus; 21AB0109 [U8908897]
