DMTA041-01EN [U8778479], Rev. C, May 2014

Connector References

6.5 P Connectors

Description

Female, coaxial

Manufacturer; number

LEMO; SWH.00.250.CTHV

Equivalent: W.W. Fischer Inc.; WDE.101.A004

Olympus; 21AB0107 [U8831532]

Suggested cable connector; number

LEMO; FFC.00.250.CTAC31

Equivalent: W.W. Fischer Inc.; S.101.A004/3.0

Olympus; 21AB0016 [U8907038]

Figure 6-6 The

P connectors

Table 16 Pinout for the

ETHERNET connector

Pin I/O Signal Description

1 Output TX+ Data transmission

2 Output TX– Data transmission

3 Input RX+ Data reception

4 — NC No connection

5 — NC No connection

6 Input RX– Data reception

7 — NC No connection

8 — NC No connection
