Set Points (if ID Number Disabled - default)
Display Action Response
With ID number disabled and in Run Mode, pressing MENU one time advances the
controller to Setpoint 1 setting directly.
SET POINT 1
Press MENU 1) Press MENU once from Run Mode.
(1 time) 2) Display flashes the first digit of Setpoint 1.
Press MAX 3) Press MAX to set the digit, 0-9.
Press MIN 4) Press MIN to activate the next digit (flashing).
5) Repeat step 3 and 4 until all digits are set.
Press ENTER 6) Controller stores new setting and returns to Run Mode.
SET POINT 2
Press MENU 1) Press MENU twice from Run Mode.
(2 times) 2) Display flashes the first digit of Setpoint 2.
3) Follow step 3 to 6 of Setpoint 1 to complete the setting.
OUTPUT REDIRECTION
Press MENU 1) Press MENU 3 times from Run Mode.
(3 times) 2) Display flashes Ò
S1.o.1
Ó in the SV window. (See previous page for more details.)
Press MAX 3) Press MAX to select the output option.
Press ENTER 4) Press ENTER to make the selection or MENU to advance to ÒInput TypeÓ.
125.5
S1.o.1
125.5
210.5
125.5
100.5
part
3
O
PERATION
: C
ONFIGURATION
M
ODE
22
