Omega MICROMEGA CN77000 series User Manual

O PERATION : C ONFIGURATION M ODE
part
3
45
Output 1 cont.
Display Action Response
AUTO PID SUBMENU:
Press ENTER 19) Display flashes
"
enbl
" or "
dsbl
".
Press MAX 20) Scroll through the available selections: Enable or Disable.
If
"Enabled", the controller can determine, by enabling Start PID, the optimum values
for the three adjustments Ñ Proportional, Reset and Rate corresponding to P, I, and
D. These values may be changed once the auto tuning is complete. If
"Disabled" is
selected, the user will manually enter these three adjustment values. If you want the
controller to do the auto
PID
and the
P
,
PI
or
PID
, first select auto disable and enter
0000 for the unwanted parameter. e.g. for
PI
enter 0000 for the rate.
Press ENTER 21) Display flashes
"stored" message and advances to "Adaptive Control" submenu.
*ADAPTIVE CONTROL SUBMENU: * (NOT INSTALLED)
Press ENTER 22) Display flashes
"
enbl
" or "
dsbl
".
Press MAX 23) Scroll through the available selections: Enable or Disable.
If
"Enabled", the Adaptive Tuning dynamically changes and updates the P, I, and D
parameters for optimum control. The adaptive tuning is useful when the load
continuously changes thereby requiring new values for
P
,
I
, and
D
.
Press ENTER 24) Display flashes
"stored" message and advances to "Anti Integral" submenu.
ADPT
ENBL
ADPT
CTRL
AUTO
ENBL
AUTO
PID
