O
PERATION
: C
ONFIGURATION
M
ODE
part
3
49
Output 1 cont.
Display Action Response
DAMPING FACTOR SUBMENU:
Press ENTER 40) Display flashes the previous
"Damping Factor" selection.
Press MAX 41) Scroll through the available selections: 0000, 0001, 0002, 0003, 0004, 0005,
0006, 0007, 0008 - Default is 0003.
Press ENTER 42) Display flashes
"
strd
" message and advances to the "Output 2" menu.
Damping Factor is a measure of speed, overshoot, and undershoot in which the process variable responds to the output
changes of the controller, which were used during the Auto Tune. This value is typically set to the ratio of Rate to Reset.
This Default value is (0003). For fast response time, this value should be decreased while for slow response time it should
be increased.
DPNG
0001
DPNG
FCTR
