part
3
O
PERATION
: C
ONFIGURATION
M
ODE
Output 1 cont.
Display Action Response
CYCLE TIME SUBMENU:
Press ENTER 37) Display flashes 1st digit of the previous
"Cycle Time" value.
Press MAX & MIN 38) Press MAX and MIN buttons to enter a new
"Cycle Time" value. (1 to 199 seconds).
Press ENTER 39) Display flashes
"stored" message and advances to "Damping Factor" submenu.
A Cycle Time selected between 1 and 199 seconds determines the total On/Off time of each proportional cycle. For example,
a 15 second Cycle Time means that every 15 seconds the output will turn on for part or all of the cycle. For Relay control
outputs, do not select a cycle time of less than 7 seconds or the relays life time will be shortened. For a Cycle Time of less
than 7 seconds select SSR or DC pulse. Use an external SSR with the DC pulse option for higher currents (higher than 1 Amp).
CYCL
0010
CYCL
TIME
To Next Page
