part
3
O
PERATION
: C
ONFIGURATION
M
ODE
62
Analog Output Option cont.
Display Action Response
Press MENU 1) Press MENU, if necessary, until the "
ANLG OUT
" prompt appears.
Press ENTER 2) Display advances to "Analog Type" submenu.
IF THE ANALOG OUTPUT OPTION IS NOT INSTALLED, THE CONTROLLER WILL
SHOW
"
NoT
_
INST
"
Press MENU Press MENU, if you receive the "Not Installed" message and advance to the
"Communication" submenu.
ANALOG RETRANSMISSION TYPE SUBMENU:
Press ENTER 3) Display flashes
"
v0lt
" or "
CUrr
".
Press MAX 4) Scroll through the available selections: Volt or Current.
Press ENTER 5) Display flashes "stored" message and advances to "Reading 1" of the Output
Reading submenu.
ANLG
VOLT
NoT
_
INST
ANLG
0UT
