O
PERATION
: C
ONFIGURATION
M
ODE
part
3
63
Analog Output Option cont.
Display Action Response
READING 1
Press ENTER 6) Display flashes 1st digit of previous ÒReading 1Ó value.
Press MAX & MIN 7) Enter "Reading 1" value.
Press ENTER 8) Display advances to
"
o
Ut1
".
OUT 1
Press ENTER 9) Display flashes 1st digit of previous ÒOut 1Ó value.
Press MAX & MIN 10) Enter "Out 1" value.
Press ENTER 11) Display advances to "Reading 2".
READING 2
Press ENTER 12) Display flashes 1st digit of previous ÒReading 2Ó value.
Press MAX & MIN 13) Enter "Reading 2" value.
Press ENTER 14) Display advances to
"
o
ut.2
".
OUT 2
Press ENTER 15) Display flashes 1st digit of previous ÒOut 2Ó value.
Press MAX & MIN 16) Enter "Out 2" value.
Press ENTER 17) Display advances to the "Communication Option" menu.
The above example is for 0-10 of the entire range of the process input and analog
output. For 0-20 mA output all you need is to set ÒOut 2Ó to
20.00
.
oUT.2
10.00
RD 2
9999
oUT.1
00.00
RD 1
0000
