O
PERATION
: C
ONFIGURATION
M
ODE
part
3
65
Communication Option cont.
Display Action Response
Press MENU 1) Press MENU, if necessary, until the "
COM7 OPTN
" prompt appears.
Press ENTER 2) Display advances to ÒCommunication Parameters" submenu.
IF THE COMMUNICATION OPTION IS NOT INSTALLED, THE CONTROLLER WILL
SHOW
"
NoT
_
INST
"
Press MENU Press MENU, if you receive the "Not Installed" message and advance to the "Remote
Setpoint" menu.
COMMUNICATION PARAMETERS SUBMENU:
Display shows "Communication Parameters" prompt.
Press ENTER 3) Display advances to
"
BAUD
" submenu.
BAUD SUBMENU:
Press ENTER 4) Display flashes previous selection for "BAUD" value.
Press MAX 5) Scroll through the available selections: 300, 600, 1200, 2400, 4800, 9600, 19.2K.
Press ENTER 6) Display flashes
"
strd
" message and advances to "Parity" submenu.
BAUD
300
_
COM7
PARA
NoT
_
INST
COM7
OPTN
To Next Page
