O PERATION : C ONFIGURATION M ODE
66
Communication Option cont.
Display Action Response
PARITY SUBMENU:
Press ENTER 7) Display flashes previous selection for "Parity".
Press MAX 8) Scroll through the available selections: NO, ODD, EVEN.
Press ENTER 9) Display flashes
"
strd
" message and advances to "Data Bit" submenu.
DATA BIT SUBMENU:
Press ENTER 7) Display flashes previous selection for "Data Bit".
Press MAX 8) Scroll through the available selections: 7 BIT, 8 BIT.
Press ENTER 9) Display flashes
"
strd
" message and advances to "Stop Bit" submenu.
STOP BIT SUBMENU:
Press ENTER 7) Display flashes previous selection for "Stop Bit".
Press MAX 8) Scroll through the available selections: 1 BIT, 2 BIT.
Press ENTER 9) Display flashes
"
strd
" message and advances to "BUS FORMAT" submenu.
BUS FORMAT SUBMENU:
Display shows
"
bus frMt
" prompt.
Press ENTER 10) Display advances to "Check Sum" submenu.
_
BUS
FRMT
STOP
1BIT
DATA
7BIT
PRTY
EVEN
