Complete Menu Structure
Level
2
Level
3
Level
4
Level
5
Level
6
Notes
RE.oN
Activate during Ramp events
SE.oN
Activate during Soak events
SEN.E
Activate if any sensor error is detected
OPL.E
Activate if any output is open loop
CyCL
____
PWM pulse width in seconds
RNGE
0-10
Analog Output Range: 0–10 Volts
0-5
0–5 Volts
0-20
0–20 mA
4-20
4–20 mA
0-24
0–24 mA
oUt2
oUt2 is replaced by output type
oUt3
oUt3 is replaced by output type (1/8 DIN can have up to 6)
PId
ACtN
RVRS
Increase to SP1 (i.e., heating)
dRCt
Decrease to SP1 (i.e., cooling)
RV.DR
Increase or Decrease to SP1 (i.e., heating/cooling)
A.to
____
Set timeout time for autotune
tUNE
StRt
Initiates autotune after StRt confirmation
GAIN
_P_
____
Manual Proportional Band setting
_I_
____
Manual Integral Factor setting
_d_
____
Manual Derivative Factor setting
rCg
____
Relative Cool Gain (heating/cooling mode)
oFst
____
Control Offset
dEAd
____
Control Dead band/Overlap band (in process unit)
%Lo
____
Low clamping limit for Pulse, Analog Outputs
%HI
____
High clamping limit for Pulse, Analog Outputs
AdPt
ENbL
Enable fuzzy logic adaptive tuning
dSbL
Disable fuzzy logic adaptive tuning
PId.2
Note: This menu is the same for PID menu.
RM.SP
oFF
Use SP1, not remote Setpoint
oN
4–20
Remote analog Input sets SP1; range: 4–20 mA
Note: This submenu is the same for all RM.SP ranges.
RS.Lo
____
Min Setpoint for scaled range
IN.Lo
____
Input value for RS.Lo
RS.HI
____
Max Setpoint for scaled range
IN.HI
____
Input value for RS.HI
0–24
0–24 mA
0–10
0–10 V
0–1
0–1 V
