Omicron CP TD1 Reference Manual

CP TD1 Reference Manual V 1.44
120
Test current (RMS, selective)
Test voltage (RMS, selective)
Capacitance Cp (equivalent parallel circuit)
Dissipation factor DF (tan δ)
f0 ± 10Hz 1.2s > 110dB at fx = f0 ± (10Hz or more)
f0 ± 20Hz 0.9s > 110dB at fx = f0 ± (20Hz or more)
Terminal Range Resolution Typical accuracy Conditions
IN A or
IN B
1
1. IN A (red) or IN B (blue), depending on the mode.
0 ... 5A AC 5 digits error < 0.3% of reading
+ 100nA
Ix < 8mA
error < 0.5% of reading Ix > 8mA
Range Resolution Typical accuracy
0 ... 12000V AC 1V error < 0.3% of reading + 1V
Range Resolution Typical accuracy Conditions
1pF... 3µF 6 digits
error < 0.05% of
reading + 0.1pF
Ix < 8mA,
Vtest = 300V ... 10kV
error < 0.2% of reading Ix > 8mA,
Vtest = 300V ... 10kV
Range Resolution Typ. accuracy Conditions
0 ... 10%
(capacitive)
5 digits error < 0.1% of reading
+0.005%
1
1. Reduced accuracy of DF at mains frequency or its harmonics. Mains frequency suppression
available by precisely selecting a mains frequency of *50Hz or *60Hz in the "Hz" column.
f=45...70Hz,
I<8mA,
Vtest = 300V ... 10kV
0 ... 100
(0...10000%)
5 digits error < 0.5% of reading
+0.02%
Vtest = 300V ... 10kV
