Capacitance and Dissipation Factor Measurement
Now we want to measure C HL. The connection diagram is shown in Figure
5-24. The measuring mode is UST-A.
Figure 5-24 Measurement of C HL in UST-A mode, C HT and C H are
guarded
IN A
IN B
C
HL
C
HT
C
H
UST-A
C = C
HL
