80-JB400-1 Rev. D 16-5
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
Wireless Panic Button Installation TEST/RESET Feature
TEST/RESET Feature
The TEST/RESET button is used to terminate the AUX function after the AUX button has
been pushed. When the TEST/RESET button is pressed alone, a self-test on the receiver
portion is activated, performing a local transmitter/receiver system test.
Activating the LOCK/UNLOCK Button
At this time, the LOCK/UNLOCK button is not used. It may be used for future applications.
Contact your Omnitracs customer service representative before wiring this feature.
Wireless Panic Button Receiver Installation
Note
Before beginning installation, inspect all wiring of the existing MCP110 unit and the wired
panic button (if installed).
The receiver should be mounted under the dash in a location that can easily be mounted with
tie wraps, preferably near the fuse panel or near the entrance of the MCP110 power cable.
The WPB receiver harness should be wired and checked for proper voltages (see Voltage
Check on page 16-8) before connecting it to the receiver.
Caution
CB radios that have been modified to increase power beyond the legal limits,
including the use of linear amplifiers (power boosters), may interfere with proper
operation of the WPB. (Code of Federal Regulations (CFR), Title 47, Part 95, Subpart E,
Section 95.667, “CB Transmitter Power”.)
Wireless Panic Button Wiring
The following sections provide wiring information for the WPB.
Grounding
1. Locate the chassis ground on the truck.
2. Attach the black (GROUND) wire of the WPB power harness to the chassis ground,
making sure it is the same potential as the battery ground of the truck.
Power
3. Locate the input power in the fuse panel (preferably, this is the same location as the
power input to the MCP110).
To Next Page
