5-41
5-4 Analog Signal
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
5
Functions
Example 1) A015/A105 = 00 (External Start Frequency)
Example 2) A015/A105 = 01 (0 Hz)
Maximum
frequency
A
012/A102/A162
A
011/A101/A161
0
A013/
A103/
A163
A014/
A104/
A164
100 %
Analog input
(FV/FI)
0 % or greater
The output frequencies of
A013/A103/A163
correspond to A011/A101/A161.
(0 V)
(0 mA)
(VR minimum)
(10 V)
(20 mA)
(VR maximum)
Analog input
Maximum
frequency
A
012/A102/A162
A
011/A101/A161
A013/
A103/
A163
A014/
A104/
A164
100 %
(FV/FI)
0 % or greater
The output frequencies of
A013/A103/A163
are 0 Hz.
(0 V)
(0 mA)
(VR minimum)
(10 V)
(20 mA)
(VR maximum)
0
