Appendix-3 Life Alarm Output
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
A
Appendix-3 Life Alarm Output
When the product life becomes close to the end for limited life parts including the on-board
smoothing capacitor or cooling fan, but excluding the main circuit smoothing capacitor, an
alarm can be output through the self-diagnostic function. Use it as a reference of the parts
replacement period.
This alarm is output through the self-diagnosis based on the expected design life (not a
guaranteed value). Therefore, it has a margin of error depending on your environment or
operation conditions.
For details, refer to "Life Assessment Monitor [d022]" on page 5-9, "Multi-function Output
Terminal Selection" on page 5-32 and "Multi-function Output Terminal Contact Selection" on
page 5-34.
