1-2 Appearance and Names of Parts
1
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
Overview
3-phase 200 V 3.7 kW
3-phase 400V 4.0 kW
3-phase 200 V 5.5, 7.5 kW
3-phase 400 V 5.5, 7.5 kW
(1) Cooling fan cover (5) Terminal block cover
(2) Cooling fan (6) Optional board cover
(3) Cooling fin (7) Backing plate
(4) Main housing
