6-58
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
141Ch AM Selection C028 R/W
00: Output frequency
01: Output current
02: Output torque (heavy load
only)
04: Output voltage
05: Input power
06: Electronic thermal load rate
07: LAD frequency
10: Cooling fin temperature
11: Output torque (signed)
(heavy load only)
13: Do not set.
16: Optional board
− 5-44
141Dh Reserved −−− − −
141Eh
Digital Current Monitor
Reference Value
C030 R/W 2000 to 20000 0.01 [%] 5-43
141Fh
Multi-function Output
Terminal P1/EDM
Contact Selection
C031 R/W
00: NO (NO contact)
01: NC (NC contact)
−
5-34
1420h
Multi-function Output
Terminal P2 Contact
Selection
C032 R/W
00: NO (NO contact)
01: NC (NC contact)
−
1421h
to
1423h
Reserved −−− − −
1424h
Multi-function Relay
Output (MA, MB) Contact
Selection
C036 R/W
00: NO (NO contact)
01: NC (NC contact)
− 5-34
1425h Reserved −−− − −
1426h
Low Current Signal
Output Mode Selection
C038 R/W
00: During acceleration/
deceleration/constant
speed
01: Only during constant
speed
−
5-129
1427h
Low Current Detection
Level
C039 R/W 0 to 20000 0.01 [%]
1428h
Overload Warning Signal
Output Mode Selection
C040 R/W
00: During acceleration/
deceleration/constant
speed
01: Only during constant
speed
−
5-115
1429h
Overload Warning Level
1
C041 R/W 0 to 20000 0.01 [%]
142Ah
Arrival Frequency During
Acceleration
C042
(HIGH)
R/W
0 to 40000 (100000) 0.01 [Hz]
5-122
142Bh
C042
(LOW)
R/W
142Ch
Arrival Frequency During
Deceleration
C043
(HIGH
R/W
0 to 40000 (100000) 0.01 [Hz]
142Dh
C043
(LOW)
R/W
142Eh
PID Deviation Excessive
Level
C044 R/W 0 to 1000 0.1 [%] 5-73
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
