6-69
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
(vi) Holding Register Number List (2nd Setting, Group F)
(vii) Holding Register Number List (2nd Setting, Groups A, b, C, H and P)
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
2103h
Acceleration Time 2
Setting
F202
(HIGH)
R/W
1 to 360000 0.01 [s]
5-24
2104h
F202
(LOW)
R/W
2105h
Deceleration Time 2
Setting
F203
(HIGH)
R/W
1 to 360000 0.01 [s]
2106h
F203
(LOW)
R/W
2107h
to
2200h
Not used −−Inaccessible −−
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
2201h
Frequency Reference
Selection 2
A201 R/W
00: Volume
01: Control circuit terminal
block
02: Digital Operator
03: Modbus communication
(Modbus-RTU)
04: Optional board
06: Pulse train frequency
07: Do not set.
10: Operation function
output
− 5-15
2202h
RUN Command
Selection 2
*1
A202 R/W
01: Control circuit terminal
block
02: Digital Operator
03: Modbus communication
(Modbus-RTU)
04: Optional board
− 5-22
2203h Base Frequency 2 A203 R/W
300 to Maximum Frequency 2 0.1 [Hz] 5-26
2204h Maximum Frequency 2 A204 R/W
Base Frequency 2 to
4000 (10000)
0.1 [Hz] 5-28
2205h
to
2215h
Reserved −−− − −
2216h
Multi-step Speed 2
Reference 0
A220
(HIGH)
R/W
0
Starting frequency to
Maximum frequency 2
0.01 [Hz] 5-63
2217h
A220
(LOW)
R/W
2218h
to
223Ah
Reserved −−− − −
*1. After changing the 2nd RUN Command Selection, provide an interval of at least 40 ms before the RUN
command is actually executed.
