9-1 Standard Specification List
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
9
Specifications
Single-phase 200 V class
CT: Heavy load, VT: Light load
Function name 1-phase 200 V
Model name
(3G3MX2-)
AB001 AB002 AB004 AB007 AB015 AB022
Applicable
motor
capacity
kW CT
0.1 0.2 0.4 0.75 1.5 2.2
VT
0.2 0.4 0.55 1.1 2.2 3.0
HP CT
1/8 1/4 1/2 1 2 3
VT
1/4 1/2 3/4 1 1/2 3 4
Rated
output
capacity
[kVA]
200 V CT
0.2 0.5 1.0 1.7 2.7 3.8
VT
0.4 0.6 1.2 2.0 3.3 4.1
240 V CT
0.3 0.6 1.2 2.0 3.3 4.5
VT
0.4 0.7 1.4 2.4 3.9 4.9
Rated input voltage 1-phase 200 V − 15% to 240 V + 10%, 50/60 Hz ± 5%
Rated output
current [A]
CT
1.3 3.0 6.3 11.5 16.8 22.0
VT
2.0 3.6 7.3 13.8 20.2 24.0
Rated output
voltage
3-phase 200 to 240 V (The output cannot exceed the incoming voltage).
Rated output
current [A]
CT
1.0 1.6 3.0 5.0 8.0 11.0
VT
1.2 1.9 3.5 6.0 9.6 12.0
Short-time
deceleration braking
torque (%)
(Discharge Resistor
not connected)
50 50 50 50 50 20
Braking
Resistor
circuit
*1
*1. The BRD usage is 10%.
Regenerative
braking
Built-in Braking Resistor circuit (separate Discharge Resistor)
Min.
connectable
resistance
[
Ω
]
100 100 100 50 50 35
Weight [kg] 1.0 1.0 1.1 1.6 1.8 1.8
Dimensions (width
× height) [mm]
68 × 128 108 × 128
Dimensions (depth)
[mm]
109 122.5 170.5
