4-30
4-2 Function Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
4
Parameter List
Level and output terminal status
C038
Low Current
Signal Output
Mode Selection
00: Enabled during
acceleration/deceleration
and constant speed
01: Enabled only during
constant speed
01 no yes −
5-129
C039
Low Current
Detection Level
0.0 to 2.00 × Rated current
Rated
current
yes yes A
C040
Overload
Warning Signal
Output Mode
Selection
00: Enabled during
acceleration/deceleration
and constant speed
01: Enabled only during
constant speed
01 no yes −
5-115
C041
Overload
Warning Level 1
0.0 to 2.00 × Rated current
Rated
current
×
1.15
yes yes
A
C241
Overload
Warning Level 2
Rated
current
×
1.15
yes yes
C042
Arrival
Frequency
During
Acceleration
0.00 to 99.99
100.0 to 400.0 (1000.)
0.00 no yes Hz
5-122
C043
Arrival
Frequency
During
Deceleration
0.00 to 99.99
100.0 to 400.0 (1000.)
0.00 no yes Hz
C044
PID Deviation
Excessive Level
0.0 to 100.0 3.0 no yes % 5-73
C045
Arrival
Frequency
During
Acceleration 2
0.00 to 99.99
100.0 to 400.0 (1000.)
0.00 no yes Hz
5-122
C046
Arrival
Frequency
During
Deceleration 2
0.00 to 99.99
100.0 to 400.0 (1000.)
0.00 no yes Hz
C047
Pulse Train
Output
Coefficient
0.01 to 99.99 1.00 yes yes − 5-43
C052
Feedback
Comparison
Signal Off Level
0.0 to 100.0 100.0 no yes %
5-73
C053
Feedback
Comparison
Signal On Level
0.0 to 100.0 0.0 no yes %
Parameter No. Function name Monitor or data range
Default
setting
Set data
Data can
be set
during
RUN
Data can be
changed
during RUN
Unit Page
