Circuit configuration
Internal
circuit
XY-CLOCK+
XY-CLOCK-
XY-SYNC+
XY-SYNC-
CHX+
CHX-
CHY+
CHY-
XY-STATUS+
XY-STATUS-
GND
FG
Connector shell
Z-CLOCK+
Z-CLOCK-
Z-SYNC+
Z-SYNC-
CHZ+
CHZ-
Z-STATUS+
Z-STATUS-
GND
FG
Connector shell
3 Configuration Units
3-67
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
3-7 Laser Interface Unit
3
3-7-1 Models and Specifications
