Exchanging Data with the CPU Unit Section 5-5
CJ1W-DA041
CJ1W-DA08V/08C
Note For the DM word addresses, m = D20000 + (unit number x 100).
DM word Bits
1514131211109876543210
D(m) Not used. Not used. Output use setting
Out-
put 4
Out-
put 3
Out-
put 2
Out-
put 1
D(m+1) Not used. Output signal range setting
Output 4 Output 3 Output 2 Output 1
D(m+2) Not used. Output 1: Output status when conversion stopped
D(m+3) Not used. Output 2: Output status when conversion stopped
D(m+4) Not used. Output 3: Output status when conversion stopped
D(m+5) Not used. Output 4: Output status when conversion stopped
DM word Bits
1514131211109876543210
D(m) Not used. Output use setting
Out-
put 8
Out-
put 7
Out-
put 6
Out-
put 5
Out-
put 4
Out-
put 3
Out-
put 2
Out-
put 1
D(m+1) Output signal range setting
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
D(m+2) Not used. Output 1: Output status when conversion stopped
D(m+3) Not used. Output 2: Output status when conversion stopped
D(m+4) Not used. Output 3: Output status when conversion stopped
D(m+5) Not used. Output 4: Output status when conversion stopped
D(m+6) Not used. Output 5: Output status when conversion stopped
D(m+7) Not used. Output 6: Output status when conversion stopped
D(m+8) Not used. Output 7: Output status when conversion stopped
D(m+9) Not used. Output 8: Output status when conversion stopped
D(m+10 to
m+17)
Not used.
D(m+18) Conversion time/resolution setting Operation mode setting
D(m+19) Output 1 scaling lower limit
D(m+20) Output 1 scaling upper limit
D(m+21) Output 2 scaling lower limit
D(m+22) Output 2 scaling upper limit
D(m+23) Output 3 scaling lower limit
D(m+24) Output 3 scaling upper limit
D(m+25) Output 4 scaling lower limit
D(m+26) Output 4 scaling upper limit
D(m+27) Output 5 scaling lower limit
D(m+28) Output 5 scaling upper limit
D(m+29) Output 6 scaling lower limit
D(m+30) Output 6 scaling upper limit
D(m+31) Output 7 scaling lower limit
D(m+32) Output 7 scaling upper limit
D(m+33) Output 8 scaling lower limit
D(m+34) Output 8 scaling upper limit
