192
Exchanging Data with the CPU Unit Section 5-5
Set Values and Stored Values
Note 1. When using a CJ1W-DA08C, these output signal range settings are invalid
and the contents will be ignored. The output signal range for the CJ1W-
DA08C is fixed at 4 to 20 mA.
2. The output signal ranges 1 to 5 V and 4 to 20 mA are switched using the
output terminal connections. For details, refer to
5-4 Wiring. (The CJ1W-
DA08V supports only voltage outputs.)
3. The values output for the signal ranges will be 0 V for the range of
±10 V,
and the minimum value for the other ranges. For details, refer to
5-6-4 Out-
put Hold Function
.
Item Contents Page
Output Use setting 0: Not used.
1: Used.
190, 196
Output signal range
(See note 1.)
00: –10 to 10 V
01: 0 to 10 V
10: 1 to 5 V/4 to 20 mA (See note 2.)
11: 0 to 5 V
190, 196
Output status when stopped 00: CLR Outputs 0 or minimum value of each range.
(See note 3.)
01: HOLD Holds output just before stopping.
02: MAX Outputs maximum value of range.
199
Conversion time/resolution
setting
00: Conversion time: 1 ms; resolution: 4,000
01: Conversion time: 250 µs; resolution: 8,000
199
Operation mode setting 00: Normal mode
01: Adjustment mode
184
Scaling settings Any value other than 0 within range of ±32,000 (8300 hex to 7D00 hex)
as long as the upper limit is not equal to the lower limit.
201
