Omron CS1W-AD081-V1 User Manual

379
Data Memory Coding Sheets Appendix C
m = D20000 + unit number x 100
D2@@45
D2@@46
D2@@47
D2@@48
D2@@49
D2@@50
D2@@51
D2@@52
DM Area
address
Setting contents
15 to 08 07 to 00
m Input use setting
m+1 Input signal range setting (inputs 1 to 8)
m+2 Input signal range setting (inputs 9 to 16)
m+3 Input 1 mean value processing setting
m+4 Input 2 mean value processing setting
m+5 Input 3 mean value processing setting
m+6 Input 4 mean value processing setting
m+7 Input 5 mean value processing setting
m+8 Input 6 mean value processing setting
m+9 Input 7 mean value processing setting
m+10 Input 8 mean value processing setting
m+11 Input 9 mean value processing setting
m+12 Input 10 mean value processing setting
m+13 Input 11 mean value processing setting
m+14 Input 12 mean value processing setting
m+15 Input 13 mean value processing setting
m+16 Input 14 mean value processing setting
m+17 Input 15 mean value processing setting
m+18 Input 16 mean value processing setting
m+19 Conversion time/resolution setting Operation mode setting
m+20 Input 1 scaling lower limit
m+21 Input 1 scaling upper limit
m+22 Input 2 scaling lower limit
m+23 Input 2 scaling upper limit
m+24 Input 3 scaling lower limit
m+25 Input 3 scaling upper limit
m+26 Input 4 scaling lower limit
m+27 Input 4 scaling upper limit
m+28 Input 5 scaling lower limit
m+29 Input 5 scaling upper limit
m+30 Input 6 scaling lower limit
m+31 Input 6 scaling upper limit
m+32 Input 7 scaling lower limit
m+33 Input 7 scaling upper limit
m+34 Input 8 scaling lower limit
m+35 Input 8 scaling upper limit
DM Area
address
Bit
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
