Omron CS1W-AD081-V1 User Manual

380
Data Memory Coding Sheets Appendix C
m = D20000 + unit number x 100
Input Use Setting
0: Not used
1: Used
Input Signal Range Setting
00:
−10 to +10 V
01: 0 to 10 V
10: 1 to 5 V/4 to 20 mA (Select voltage/current in DM word m+52)
10: 0 to 5 V
m+36 Input 9 scaling lower limit
m+37 Input 9 scaling upper limit
m+38 Input 10 scaling lower limit
m+39 Input 10 scaling upper limit
m+40 Input 11 scaling lower limit
m+41 Input 11 scaling upper limit
m+42 Input 12 scaling lower limit
m+43 Input 12 scaling upper limit
m+44 Input 13 scaling lower limit
m+45 Input 13 scaling upper limit
m+46 Input 14 scaling lower limit
m+47 Input 14 scaling upper limit
m+48 Input 15 scaling lower limit
m+49 Input 15 scaling upper limit
m+50 Input 16 scaling lower limit
m+51 Input 16 scaling upper limit
m+52 Voltage/current range setting (Only for 1 to 5 V and 4 to 20 mA.)
DM Area
address
Setting contents
15 to 08 07 to 00
07 06 05 04 03 02 01 00
Input
8
Input
7
Input
6
Input
5
Input
4
Input
3
Input
2
Input
1
15 14 13 12 11 10 09 08
Input
16
Input
15
Input
14
Input
13
Input
12
Input
11
Input
10
Input
09
05-14 13-1211-10 09-08 07-06 05-04 03-02 01-00
Input
8
Input
7
Input
6
Input
5
Input
4
Input
3
Input
2
Input
1
05-14 13-1211-10 09-08 07-06 05-04 03-02 01-00
Input
16
Input
15
Input
14
Input
13
Input
12
Input
11
Input
10
Input
9
