CompoNet Network Specifications Section 1-2
■ Baud Rate of 3 Mbps
Note The maximum number of nodes per branch is the maximum number of Slave
Units or Repeater Units that can be connected to one branch line using multi-
drop or T-branch connections.
■ Baud Rate of 1.5 Mbps
Note (1) This is the maximum number of Slave Units and Repeater Units com-
bined that can be connected to a branch line by using multidrop connec-
tions and/or T-branching. T-branching creates a sub-branch.
(2) The trunk line does not support branching. The trunk line and sub-trunk
lines support only multidrop connections.
(3) Branch lines support branching to sub-branch lines.
Item Round Cable I or II Flat Cable I or II
Length per trunk line or sub-trunk line (maximum
length with two Repeater Units)
30 m (90 m) 30 m (90 m)
Branch line length 0.5 m 0.5 m
Total branch line length 8 m 8 m
Restrictions on branch line locations 3 branches / m 3 branches / m
Number of Units per branch (See note.) 1 1
Maximum sub-branch line length Not supported Not supported
Total sub-branch line length Not supported Not supported
Number of Slave Units (including Repeater Units)
per trunk line or sub-trunk line
32 32
Item Round Cable I Round Cable II, Flat
Cable I, or Flat
Cable II
Without branch
lines
With branch lines
Length per trunk line or sub-trunk line (maximum
length with two Repeater Units)
100 m (300 m) 30 m (90 m) 30 m (90 m)
Branch line length Not supported (See
note 2.)
2.5 m 2.5 m
Total branch line length Not supported (See
note 2.)
25 m 25 m
Restrictions on branch line locations --- 3 branches / m 3 branches / m
Number of Units per branch (See note 1.) 3 3
Maximum sub-branch line length Not supported 0.1 m (See note 3.)
Total sub-branch line length Not supported 2 m (See note 3.)
Number of Slave Units (including Repeater Units)
per trunk line or sub-trunk line
32 32 32
