FINS Commands Addressed to CompoNet Master Units and Responses Appendix A
End Codes (MRES/SRES)
Error Codes
Parameter Details
Destination (Remote Node) Node Address
Provides the node address of a remote device.
Service Code
Specifies the service code defined for the explicit message.
End code (hex) Contents
0000 Normal completion
0101 The network for the local node is not operating.
0201 The network for the remote node is not operating.
0204 The message cannot be sent because the remote node is busy.
0205 Monitoring time expired with no response from the remote node.
1001 The maximum permissible command length was exceeded.
1002 The command length is less than the minimum command length.
1004 The command format is not suitable.
1005 There is a header error. (The destination address setting is illegal.)
110B The response exceeded the maximum response length.
2211 The Unit is busy. (The memory required for internal transmission processing
cannot be reserved.)
2609 The required settings have not been made.
End code (hex) Contents
0x02FF A required resource was not available.
0x08FF A requested service was not supported.
0x09FF Attribute data is illegal.
0x0BFF The specified object was already in the requested state.
0x0CFF The requested service cannot be executed for the specified object.
0x0EFF An unchangeable attribute was specified.
0x10FF The requested service cannot be executed for the specified device.
0x11FF The response data is too long to be processed.
0x13FF There is insufficient data provided for processing.
0x14FF The attribute is undefined.
0x15FF Invalid data is included.
0x16FF The object is not implemented.
0x19FF The save operation failed.
0x1F@@ A header error occurred. (Detailed error information is stored in @@.)
0x20FF There is an error in the parameters.
0x28FF A class, instance, or attribute that is not implemented was specified for the
member ID of the requested service.
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Classification
0x0: Master Unit
0x1: Normal Input or I/O Unit
0x2: Word Output Unit
0x4: Bit Input or I/O Unit
0x5: Bit Output Unit
0x7: Repeater Unit
0000Master Unit: Always 0.
Word Slave Unit: 0 to 0x3F
Bit Slave Unit: 0 to 0x7F
Repeater Unit: 0 to 0x3F
