Conventions Used in This Manual
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
Conventions Used in This Manual
In this manual, “E5CC/E5EC” or “E5CC-800/E5EC-800” is used to indicated the E5CC/E5EC-@-8@@
Simple-type Digital Controllers.
z Differences in I/O Configurations
z Differences in Main Functions
The Simple-type Digital Controllers do not support the following functions.
• Remote SP Input
• Transfer Output
• Simple Program Function
• Extraction of Square Root
• MV at Stop and Error
• MV Change Rate Limit
• User Calibration
• Logic Operations
• Setup Tool: CX-Thermo (EST2-2C-MV4)
• USB-Serial Conversion Cable
Differences between Standard-type and Simple-type Digital Controllers
E5CC E5EC
Simple type
Standard
type
Simple type
Standard
type
Control
outputs 1
and 2
RX (1 relay output) Supported. Supported. Supported. Supported.
QX (1 voltage output (for driving SSR)) Supported. Supported. Supported. Supported.
CX (1 current output) Supported. Supported. Supported. Supported.
QQ (2 voltage outputs (for driving SSRs)) Not supported. Supported. Not supported. Supported.
QR (1 voltage output (for driving SSR)
and 1 relay output)
Not supported. Not supported. Supported. Supported.
RR (2 relay outputs) Not supported. Not supported. Supported. Supported.
CC (2 current outputs) Not supported. Not supported. Not supported. Supported.
CR (1 current output and 1 relay output) Not supported. Not supported. Supported. Not supported.
No. of
auxiliary
outputs
0 Not supported. Supported. Not supported. Not supported.
2 Supported. Supported. Supported. Supported.
3 Not supported. Supported. Not supported. Not supported.
4 Not supported. Not supported. Not supported. Supported.
Power supply
voltage
100 to 240 VAC Supported. Supported. Supported. Supported.
24 VAC/DC Supported. Supported. Supported. Supported.
Terminal type Screw terminals Supported. Supported. Supported. Supported.
Screw terminals (with cover) Not supported. Supported. Not supported. Supported.
Input type Universal input Supported. Supported. Supported. Supported.
Option Event inputs Supported. Supported. Supported. Supported.
Communications (RS-485) Supported. Supported. Supported. Supported.
Remote SP input Not supported. Supported. Not supported. Supported.
HB alarm and HS alarm Supported. Supported. Supported. Supported.
Transfer output Not supported. Supported. Not supported. Supported.
Top-panel Setup Tool port Not supported. Supported. Not supported. Supported.
Front-panel Setup Tool port Not supported. Not supported. Not supported. Supported.
