Conventions Used in This Manual
16
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
The following abbreviations are used in parameter names, figures, and other descriptions. These
abbreviations mean the following:
* “EU” stands for Engineering Unit. EU is used as the minimum unit for engineering units such as °C, m, and g.
The size of the EU depends on the input type. For example, when the input temperature setting range is −200
to 1,300°C, 1 EU is 1°C, and when the input temperature setting range is −20.0 to 500.0°C, 1 EU is 0.1°C.
For analog inputs, the size of the EU depends on the decimal point position of the scaling setting, and 1 EU is
the minimum scaling unit.
The following tables show the correspondence between the symbols displayed on the displays and
alphabet characters.
Model Notation
Event inputs Communications
HB alarm and HS
alarm
E5CC/EC-@-800 --- --- ---
E5CC-@-801 2 --- 1
E5CC-@-802 --- RS-485 1
E5CC/EC-@-804 2 RS-485 ---
E5EC-@-808 2 RS-485 1
E5EC-@-810 4 --- 1
Meanings of Abbreviations
Symbol Term
PV Process value
SP Set point
SV Set value
AT Au to- tuni ng
ST Self-tuning
EU Engineering unit*
LBA Loop burnout alarm
HB Heater burnout
HS Heater short
How to Read Display Symbols
abcdefghijklm
ABCDEFGH I JKLM
nopqrstuVwxyz
NOPQRSTUVWXYZ
