Preface
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
Preface
The E5CC and E5EC are Digital Controllers. The main functions and characteristics of these Digital
Controllers are as follows:
• Any of the following types of input can be used: thermocouple, platinum resistance thermometer,
infrared sensor, analog voltage, or analog current.
• Either standard or heating/cooling control can be performed.
• Both auto-tuning and self-tuning are supported.
• Event inputs can be used to switch set points (multi-SP function), switch between RUN and STOP
status, switch between automatic and manual operation, and perform other operations.
• Heater burnout detection and heater short (HS) alarms functions are supported. (Applicable models
with heater burnout detection function.)
• Communications are supported. (Applicable to models with communications.)
• The structure is waterproof (IP66).
• Conforms to UL, CSA, and IEC safety standards and EMC Directive.
Read this manual thoroughly and be sure you understand it before attempting to use the Digital Control-
ler and use the Digital Controller correctly according to the information provided. Keep this manual in a
safe place for easy reference.
There are two types of E5CC/E5EC Digital Controllers: The E5CC/E5EC-@-0@@ Standard-type Digital
Controllers and the Simple-type E5CC/E5EC-@-8@@ Digital Controllers. This manual describes how to
use the E5CC/E5EC-@-8@@ Simple-type Digital Controllers. For detailed specifications of functions,
refer to the E5CC/E5EC Digital Temperature Controllers User’s Manual (Cat. No. H174). In this manual,
“E5CC/E5EC” or “E5CC-800/E5EC-800” is used to indicated the E5CC/E5EC-@-8@@ Simple-type Dig-
ital Controllers. Refer to the following manual for further information on communications: E5CC/E5EC
Digital Temperature Controllers Communications Manual (Cat. No. H175).
© OMRON, 2012
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form,
or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission of
OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is
constantly striving to improve its high-quality products, the information contained in this manual is subject to change
without notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no
responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information
contained in this publication.
