A Appendices
A - 16
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
*1 Any settings that are entered will be ignored.
*2 This function can be set for heating/cooling control, but the function will be disabled.
*3 These settings can be used only for models with communications.
Event Input
Assignment 1
ev-1 NONE: None
STOP: RUN/STOP
MANU: Auto/Manual Switch
PRST: Program Start
*1
DRS: Invert Direct/Reverse Operation
AT-2: 100% AT Execute/Cancel
AT-1: 40% AT Execute/Cancel
*2
WTPT: Setting Change Enable/Disable
CMWT: Communications write enable/disable
*3
LAT: Alarm Latch Cancel
MSP0: Multi-SP No. switching bit 0
MSP1: Multi-SP No. switching bit 1
MSP2: Multi-SP No. switching bit 2
none
stop
manu
prst
drs
at-2
at-1
wtpt
cmwt
lat
msp0
msp1
msp2
MSP0 None
Event Input
Assignment 2
ev-2 Same as Event Input Assignment 1. Same as
Event Input
Assignment
1.
STOP None
Event Input
Assignment 3
ev-3 Same as Event Input Assignment 1. Same as
Event Input
Assignment
1.
NONE None
Event Input
Assignment 4
ev-4 Same as Event Input Assignment 1. Same as
Event Input
Assignment
1.
NONE None
Move to Advanced
function Setting Level
amov −1,999 to 9,999 0 None
Parameters Characters Setting (monitor) value Display Default Unit

Omron E5CC-800 Specifications

General

Communication	RS-485 (optional)
Protection Rating	IP66 (front panel)
Input Type	Thermocouple, RTD, analog input
Output Type	Relay, voltage, current
Supply Voltage	100-240 VAC, 24 VAC/VDC
Size	48 x 48 mm
Control Output	Relay, voltage, current
Ambient Operating Temperature	55 °C
Control Method	ON/OFF, 2-PID
Ambient Operating Humidity	35 to 85% RH (non-condensing)
Mounting	Panel mount
