Omron E5CN User Manual

119
Using the Simple Program Function Section 4-15
Operation Level
Initial Setting Level
1. Press the O Key for at least three seconds to move from the operation
level to the initial setting level.
Initial Setting Level
2. Select the Program Pattern parameter by pressing the M Key.
3. Use the U Key to set the parameter to STOP.
Operation Level
4. Press the O Key for at least one second to move from the initial setting
level to the operation level.
Adjustment Level
5. Press the O Key to move from the operation level to the adjustment level.
Adjustment Level
6. Select the Soak Time parameter by pressing the M Key.
7. Use the U Key to set the parameter to 10. (The soak time unit is set in
Soak Time Unit parameter in the advanced function setting level. The de-
fault is m (minutes).
Adjustment Level
8. Select the Wait Band parameter by pressing the M Key.
9. Use the U Key to set the parameter to 3.0.
Operation Level
10. Press the O Key to move from the adjustment level to the operation level.
C
25
100
PV/SP
in-t
5
Input Type
ptrn
off
Program Pattern
ptrn
stop
C
25
100
PV/SP
l.adj
Adjustment Level
Display
soak
1
Soak Time
soak
10
wt-b
off
Wait Band
wt-b
3.0
C
25
100
PV/S
P

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
