Omron E5CN User Manual

125
Setting the Width of MV Variation Section 4-18
3. Use the U Key to select 2-PID control.
4. Press the M Key to select the ST parameter.
5. Press the D Key to select OFF.
Operation Level
6. Press the O Key for at least one second to move from the initial setting
level to the operation level.
Adjustment Level
7. Press the O Key to move from the operation level to the adjustment level.
8. Press the M Key to select the MV Change Rate Limit parameter.
9. Use the U Key to set the parameter to 5.0.
Operation Level
10. Press the O Key to return to the operation level.
cntl
pid
PID·ON/OFF
st
on
ST
st
off
ST
C
25
100
PV/SP
l.adj
orl
0.0
MV
Change
Rate Limit
orl
5.0
MV
Change
Rate Limit
C
25
100
PV/S
P

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
