168
Adjustment Level Section 5-4
This parameter measures the heater current from the CT input used for
detecting SSR short-circuits.
This parameter measures and displays the heater current when the heater is
OFF.
• HS alarms are not detected if the control output (heating) OFF time is
100 ms or less.
• ffff is displayed when 55.0 A is exceeded.
• If an HS alarm 1 alarm is output, the HA indicator will light and the No. 1
display for the leakage current 1 monitor will flash.
■ Related Parameters
HS alarm 1, HS alarm 2 (adjustment level): Page 168
HS alarm use (advanced function setting level): Page 216
Error Displays lcr1: Page 261
This parameter sets the current for the HS alarm to be output.
• An HS alarm is output when the leakage current value exceeds the set-
ting of this parameter.
• When the set value is 50.0, the HS alarm output is turned OFF. When the
set value is 0.0, the HS alarm output is turned ON.
■ Related Parameters
Leakage current 1 monitor (adjustment level): Page 168
HS alarm, HS alarm latch, HS alarm hysteresis (advanced function setting
level): Page 216
lcr1 Leakage Current 1 Monitor
Heater burnout, HS alarms, and
heater overcurrent detection must be
supported.
Alarm 1 must be assigned.
The HS Alarm parameter must be
set to ON.
Monitor range Unit
0.0 to 55.0 A
Function
Monitor
See
See
hs1 HS Alarm 1
Heater burnout, HS alarms, and
heater overcurrent detection must be
supported.
Alarm 1 must be assigned.
The HS Alarm parameter must be
set to ON.
Setting range Unit Default
0.0 to 50.0 A 50.0
Function
Setting
See
See
