196
Initial Setting Level Section 5-7
• Multi-SP is a function for setting set points 0 to 3 in advance, and switch-
ing between these set points using a combination of event input ON/OFF
signals.
• The Number of Multi-SP Uses parameter is used to switch between using
two and four preset set points.
• Whether the Event Input Assignments 1 and 2 parameters are displayed
or hidden is determined by the Number of Multi-SP Uses parameter set-
ting.
Controllers with Event Inputs 1 and 2 (Two Event Inputs)
The following tables show the relationships between ON/OFF combinations of
event inputs 1 and 2 and selected set points.
Number of Multi-SP Uses: 1:
Number of Multi-SP Uses: 2
• The following table shows the functions assigned when an Event Input
Assignment (1 or 2) is displayed.
ev-m Number of Multi-SP Uses
An event input must be assigned.
Setting range Default
0 to 2 1
Event input assignment 1 Event input assignment 2
Number of multi-
SP uses
0 Displayed (Multi-SP not used).
1 Hidden (Multi-SP, 2 points). Displayed (Event input 2 not
used as multi-SP switch).
2 Hidden (Multi-SP, 4 points).
Even input 1 Selected set point
OFF Set point 0
ON Set point 1
Even input 1 Even input 2 Selected set point
OFF OFF Set point 0
ON OFF Set point 1
OFF ON Set point 2
ON ON Set point 3
Setting Function
none None
stop RUN/STOP
manu Auto/Manual Switch
prst Program start (See note 1.)
drs Invert Direct/Reverse Operation
at-2 100% AT Execute/Cancel
at-1 40% AT Execute/Cancel (See note 2.)
wtpt Setting Change Enable/Disable
lat Alarm Latch Cancel
Function
Setting
To Next Page
