Omron E5CN User Manual

198
Initial Setting Level Section 5-7
Note (1) PRST (Program Start) can be set even when the Program Pattern param-
eter is set to OFF, but the function will be disabled.
(2) This function can be set for heating/cooling control, but the function will
be disabled.
■ Related Parameter
SP0 to SP3 (adjustment level): Page 170
Number of multi-SP uses (initial setting level): Page 196
This parameter enables and disables square root extraction.
■ Related Parameter
Extraction of square root low-cut point (adjustment level): Page 178
• Set the Move to Advanced Function Setting Level parameter set value to
“
−169.”
• Move to the advanced function setting level either by pressing M Key or
O Key or by waiting or two seconds to elapse.
■ Related Parameter
Initial setting/communication protect (protect level): Page 144
See
See
sqr Extraction of Square Root Enable
An analog input must be supported.
Setting range Default
on: Enabled, off: Disabled None
Function
Setting
See
See
amov Move to Advanced Function Setting Level
The Initial Setting/Communications
Protect parameter must be set to 0.
Function
See
See

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
