Omron E5CN User Manual

201
Advanced Function Setting Level Section 5-8
• This parameter returns all parameter settings to their defaults.
• After the initialization, the set value automatically turns off.
This parameter enables switching between set points 0 to 3 by operating the
keys on the front panel.
Prerequisites
• A model without event inputs
• The Number of Multi-SP Uses parameter set to 0 on a model with event
inputs
on: Set points 0 to 3 can be selected.
off: Set points 0 to 3 cannot be selected.
• Default: OFF
■ Related Parameters
Multi-SP set point setting (operation level): Page 151
Number of multi-SP uses (Initial setting level): Page 196
• This parameter sets the time unit for the rate of change during SP ramp
operation.
■ Related Parameters
Ramp SP monitor (operation level): Page 151
SP ramp set value (adjustment level): Page 177
init Parameter Initialization
Setting range Default
off: Initialization is not executed. off
fact: Initializes to the factory settings described in the manual.
Function
Setting
mspu Multi-SP Uses
The model must not support event
inputs, or the number of multi-SP
uses must be 0.
Function
Setting
See
See
spru SP Ramp Time Unit
The ST parameter must be set to
OFF.
Setting range Default
s: EU/s, m: EU/min, h: EU/h m
Function
Setting
See
See

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
