Advanced Function Setting Level Section 5-8

• This parameter sets the output status of auxiliary outputs 1 to 3.

• When Close in Alarm is set, the status of the auxiliary output function is

output unchanged. When Open in Alarm is set, the status of the auxiliary

output function is reversed before being output. The following table shows

the relationship between the auxiliary output function, auxiliary output,

and operation displays (SUB1 to SUB3).

■ Related Parameters

Auxiliary output 1 to 3 assignment (advanced function setting level): Pages

221 to 223

• Set to use the heater burnout alarm.

sb*n

Auxiliary Output * Open in Alarm

(*: 1 to 3)

Auxiliary output 1, 2, or 3 must be

assigned.

Auxiliary output

function

Auxiliary output Operation display

(SUB1 to SUB3)

Close in Alarm ON ON Lit

OFF OFF Not lit

Open in Alarm ON OFF Lit

OFF ON Not lit

Setting range Default

n-o: Close in alarm, n-c: Open in alarm n-o

Function

Setting

See

hbu HB ON/OFF

Heater burnout, HS alarms, and

heater overcurrent detection must be

supported.

Alarm 1 must be assigned.

Setting range Default

on: Enabled, off: Disabled on

Function

Setting
