209
Advanced Function Setting Level Section 5-8
• The output is turned OFF when switching to the initial setting level, com-
munications setting level, advanced function setting level, or calibration
level.
• If an auxiliary output is set to close in alarm, the output is kept closed. If it
is set to open in alarm, it is kept open.
■ Related Parameters
Alarm value 1 to 3: Page 156 to 157, Alarm value upper limit 1 to 3: Page 158
to 159, Alarm value lower limit 1 to 3: Page 158 to 159 (operation level)
Alarm 1 to 3 type (initial setting level): Page 191 to 193
Standby sequence reset: Page 202, Auxiliary output 1 to 3 open in alarm:
Page 203 (advanced function setting level), Alarm 1 to 3 hysteresis: Page 192
(initial setting level)
Event input assignment 1 and 2 (initial setting level): Page 197
HB ON/OFF: Page 203, PF setting: Page 228 (advanced function setting
level)
• This parameter sets the key pressing time required to move to the protect
level from the operation level, the adjustment level, or monitor/setting item
level.
■ Related Parameters
Operation/adjustment protect, Initial setting/communications protect, Setting
change protect (protect level): Page 144
• When this parameter is set to ON, the output assigned for alarm 1 turns
ON for input errors.
Note For details on input errors, refer to Error Displays on page 259.
• The alarm 1 output is an OR output of alarm 1, HB alarm/HS alarm,
heater overcurrent alarm, and input error.
• Output is turned OFF when switching to the initial setting level, communi-
cations setting level, advanced function setting level, or calibration level.
Setting range Default
on: Enabled, off: Disabled off
Setting
See
See
prlt Move to Protect Level Time
Setting range Unit Default
1 to 30 Second 3
Function
Setting
See
See
sero Input Error Output
Alarm 1 must be assigned, but not to
a work bit output.
Function
Setting
To Next Page
