Omron E5CN User Manual

214
Advanced Function Setting Level Section 5-8
This parameter sets the shift method for thermocouple or resistance ther-
mometer inputs.
• When the input type is thermocouple or resistance thermometer, set
either a 1-point shift or a 2-point shift.
■ Related Parameters
Temperature input shift, Upper-limit temperature input shift value, Lower-limit
temperature input shift value (adjustment level): Page 170
Input type (initial setting level): Page 184
This parameter sets whether or not the MV at Stop and MV at PV Error
parameters are to be displayed.
• Set whether or not the MV at Stop and MV at PV Error parameters are to
be displayed.
■ Related Parameters
MV at stop, MV at PV error (adjustment level): Page 176
istp Input Shift Type
The input type must be thermocou-
ple or resistance thermometer.
Setting range Default
ins1: 1-point shift, ins2: 2-point shift ins1
Function
Setting
See
See
mvse MV at Stop and Error Addition
The control must be set to 2-PID
control.
Setting range Default
on: Displayed, off: Not displayed off
Function
Setting
See
See

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
