Omron E5CN User Manual

213
Advanced Function Setting Level Section 5-8
Alarm 1, 2, or 3 outputs are prevented from turning ON until after the delay
times set in these parameters have elapsed.
• Set the time for which the ON delay is to be enabled.
• To disable the ON delay, set 0.
■ Related Parameters
Alarm 1 to 3 type (initial setting level): Pages 191 to 193
Alarm 1, 2, or 3 outputs are prevented from turning OFF until after the delay
times set in these parameters have elapsed.
• Set the time for which the OFF delay is to be enabled.
• To disable the OFF delay, set 0.
■ Related Parameters
Alarm 1 to 3 type (initial setting level): Pages 191 to 193
a1on Alarm 1 ON Delay
Alarm 1 must be assigned, and the
alarm 1 type must not be 0, 12, or
13.
a2on Alarm 2 ON Delay
Alarm 2 must be assigned, and the
alarm 2 type must not be 0, 12, or
13.
a3on Alarm 3 ON Delay
Alarm 3 must be assigned, and the
alarm 3 type must not be 0, 12, or
13.
Setting range Unit Default
0 to 999 Second 0
Function
Setting
See
See
a1of Alarm 1 OFF Delay
Alarm 1 must be assigned, and the
alarm 1 type must not be 0, 12, or
13.
a2of Alarm 2 OFF Delay
Alarm 2 must be assigned, and the
alarm 2 type must not be 0, 12, or
13.
a3of Alarm 3 OFF Delay
Alarm 3 must be assigned, and the
alarm 3 type must not be 0, 12, or
13.
Setting range Unit Default
0 to 999 Second 0
Function
Setting
See
See

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
