Omron E5CN User Manual

231
Advanced Function Setting Level Section 5-8
The display below the decimal point in the PV can be hidden for temperature
inputs.
• The PV decimals below the decimal point can be hidden by setting the PV
Decimal Point Display parameter to OFF. When this parameter is set to
ON, the display below the decimal point will appear according to the input
type setting.
■ Related Parameters
Input type (initial setting level): Page 184
• The PV in the No. 1 display for the PV/SP, PV, or PV/Manual MV Screen is
alternately displayed in 0.5-s cycles with the control and alarm status
specified for the PV status display function.
■ Related Parameters
Process value/set point, PV (operation level): Page 149
PV/MV (manual MV) (manual control level): Page 181
pvdp PV Decimal Point Display
The input type must be set to tem-
perature input.
Setting range Default
on: ON, off: OFF ON
Function
Setting
See
See
pvst PV Status Display Function
Monitor range Default
off: No PV status display off
manu: MANU is alternately displayed during manual control.
stop: STOP is alternately displayed while operation is stopped.
alm1: ALM1 is alternately displayed during Alarm 1 status.
alm2: ALM2 is alternately displayed during Alarm 2 status.
alm3: ALM3 is alternately displayed during Alarm 3 status.
alm: ALM is alternately displayed when Alarm 1, 2, or 3 is set to ON.
ha: HA is alternately displayed when a heater burnout alarm, HS alarm,
or heater overcurrent alarm is ON.
Monitor
See
See

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
