Omron E5CN User Manual

271
Appendix
Note (1) Set “None” as the unit for analog inputs (23: 0 to 50 mV).
(2)
(2.1) Initialized when the transfer output type is changed.
Initialized if the input type, temperature unit, scaling upper/lower limit, or SP upper/
lower limit is changed when the transfer output type is SP, ramp SP, or PV.
(When initialized by the initializing settings, it is initialized to 100.0/0.0.)
(3) PRST (Program Start) can be set even when the Program Pattern parameter is set to OFF, but the
function will be disabled.
Linear Current Out-
put
o1-t 4-20: 4 to 20 mA
0-20: 0 to 20 mA
4-20, 0-20 4-20 None
Multi-SP Use ev-m 0 to 2 1 None
Event Input Assign-
ment 1
ev-1 None: None
STOP: RUN/STOP
MANU: Auto/Manual
PRST: Program Start (See
note 3.)
DRS: Invert Direct/Reverse
Operation
AT-2: 100% AT Execute/Can-
cel
AT-1: 40% AT Execute/Cancel
WTPT: Setting Change
Enable/Disable
LAT: Alarm Latch Cancel
none
stop
manu
prst
drs
at-2
at-1
wtpt
lat
NONE None
Event Input Assign-
ment 2
ev-2 None: None
STOP: RUN/STOP
MANU: Auto/Manual
PRST: Program Start (See
note 3.)
DRS: Invert Direct/Reverse
Operation
AT-2: 100% AT Execute/Can-
cel
AT-1: 40% AT Execute/Cancel
WTPT: Setting Change
Enable/Disable
LAT: Alarm Latch Cancel
none
stop
manu
prst
drs
at-2
at-1
wtpt
lat
STOP None
Extraction of Square
Root Enable
sqr OFF, ON off,
on
OFF None
Move to Advanced
function Setting
Level
amov −1999 to 9,999 0 None
Parameters Characters Setting (monitor) value Display Default Unit Set value
Transfer output
type
Setting (monitor) range Default (transfer output
upper/lower limits)
(See note 2.1.)
Unit
Set Point SP lower limit to SP upper limit SP upper limit/lower limit EU
Set Point During SP
Ramp
SP lower limit to SP upper limit SP upper limit/lower limit EU
PV Temperature: Input setting
range lower limit to input setting
range upper limit
Input setting range upper/
lower limit
EU
Analog: Scaling lower limit to
scaling upper limit
Scaling upper/lower limit EU
MV Monitor (Heat-
ing)
Standard: −5.0 to 105.0
Heating/cooling: 0.0 to 105.0
100.0/0.0 %
MV Monitor (Cool-
ing)
0.0 to 105.0 100.0/0.0 %
