277
Appendix
Note (1) Set “None” as the unit for analog inputs (23: 0 to 50 mV).
(2) The setting range depends on whether control output 1 is a current output or voltage output (for driv-
ing SSR).
(3) P.END (program end output) can be set even when the program pattern is set to OFF, but the func-
tion will be disabled.
(4) Turns ON when either the control output 1 or 2 ON/OFF count alarm is ON.
(5) Displayed when logic operations are used. For detail, refer to 4-22 Logic Operations.
Protect Level
Communications Setting Level
Note When setting CWF, either CompoWay/F or SYSWAY can be used as the communications protocol.
(CompoWay/F and SYSWAY are automatically identified by the command frames.)
Control Output 1 ON/
OFF Count Alarm
Set Value
ra1 0 to 9999 0 100 times
Control Output 2 ON/
OFF Count Alarm
Set Value
ra2 0 to 9999 0 100 times
ON/OFF Counter
Reset
rac 0: Disable the counter reset
function.
1: Reset the control output 1
ON/OFF counter.
2: Reset the control output 2
ON/OFF counter.
0None
Move to Calibration
Level
cmov −1999 to 9,999 0 None
Parameters Characters Setting (monitor) value Display Default Unit Set value
Parameters Characters Setting (monitor) value Display Default Unit Set value
Move to Protect level pmov −1999 to 9,999 0 None
Operation/Adjustment Protect oapt 0 to 3 0 None
Initial Setting/Communica-
tions Protect
icpt 0 to 2 1 None
Setting Change Protect wtpt OFF, ON off, on OFF None
PF Key Protect pfpt OFF, ON off, on OFF None
Parameter Mask Enable pmsk OFF, ON off, on ON None
Password to Move to Protect
Level
prlp −1999 to 9,999 0 None
Parameters Characters Setting (monitor) value Display Default Unit Set value
Protocol Setting psel CompoWay/F (SYSWAY),
Modbus (See note.)
cwf, mod Compo-
Way/F
(SYSWAY)
None
Communications Unit No. u-no 0 to 99 1 None
Communications Baud
Rate
bps 1.2, 2.4, 4.8, 9.6, 19.2, 38.4,
or 57.6
1.2, 2.4,
4.8, 9.6,
19.2, 38.4,
57.6
9.6 kbps
Communications Data
Length
len 7, 8 7 Bit
Communications Stop
Bits
sbit 1, 2 2 Bit
Communications Parity prty None, Even, Odd none,
even, odd
Even None
Send Data Wait Time sdwt 0 to 99 20 ms

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
