Appendix
Monitor/Setting Item
1
pfd1 0: Disabled
1: PV/SP/Multi-SP
2: PV/SP/MV
3: PV/SP/Soak time remain
4: Proportional band (P)
5: Integral time (I)
6: Derivative time (D)
7: Alarm value 1
8: Alarm value upper limit 1
9: Alarm value lower limit 1
10: Alarm value 2
11: Alarm value upper limit 2
12: Alarm value lower limit 2
13: Alarm value 3
14: Alarm value upper limit 3
15: Alarm value lower limit 3
1None
Monitor/Setting Item
2
pfd2 0 to 15: Same as for Monitor/
Setting Item 1.
0None
Monitor/Setting Item
3
pfd3 0 to 15: Same as for Monitor/
Setting Item 1.
0None
Monitor/Setting Item
4
pfd4 0 to 15: Same as for Monitor/
Setting Item 1.
0None
Monitor/Setting Item
5
pfd5 0 to 15: Same as for Monitor/
Setting Item 1.
0None
PV/SP Display
Screen Selection
spdp 0: PV/SP
1: PV/SP/Multi-SP, PV/SP/MV
2: PV/SP/MV, PV/SP/Multi-SP
3: PV/SP/Multi-SP
4: PV/SP/MV
5: PV/SP/Multi-SP, PV/SP/
Soak Time Remain
6: PV/SP/MV, PV/SP/Soak
Time Remain
7: PV/SP/Soak Time Remain
4None
MV Display Selec-
tion
odsl O: MV (Heating)
C-O: MV (Cooling)
o
c-o
0None
PV Decimal Point
Display
pvdp OFF, ON off, on ON None
PV Status Display
Function
pvst OFF: OFF
MANU: Manual
STOP: Stop
ALM1: Alarm 1
ALM2: Alarm 2
ALM3: Alarm 3
ALM: Alarm 1 to 3 OR status
HA: Heater alarm
off
manu
stop
alm1
alm2
alm3
alm
ha
OFF None
SV Status Display
Function
svst OFF: OFF
MANU: Manual
STOP: Stop
ALM1: Alarm 1
ALM2: Alarm 2
ALM3: Alarm 3
ALM: Alarm 1 to 3 OR status
HA: Heater alarm
off
manu
stop
alm1
alm2
alm3
alm
ha
OFF None
Display Refresh
Period
d.ref OFF, 0.25, 0.5, 1.0 0.25 Second
Control Output 1 ON/
OFF Count Monitor
ra1m 0 to 9999 100 times
Control Output 2 ON/
OFF Count Monitor
ra2m 0 to 9999 100 times
Parameters Characters Setting (monitor) value Display Default Unit Set value
