275
Appendix
Auxiliary Output 1
Assignment
sub1 NONE: No assignment
O: Control output (heat-
ing)
C-O: Control output (cool-
ing)
ALM1: Alarm 1
ALM2: Alarm 2
ALM3: Alarm 3
P.END: Program end output
(See note 3.)
RALM: Control output ON/
OFF count alarm
(See note 4.)
WR1: Work bit 1 (See note 5.)
WR2: Work bit 2 (See note 5.)
WR3: Work bit 3 (See note 5.)
WR4: Work bit 4 (See note 5.)
WR5: Work bit 5 (See note 5.)
WR6: Work bit 6 (See note 5.)
WR7: Work bit 7 (See note 5.)
WR8: Work bit 8 (See note 5.)
none
o
c-o
alm1
alm2
alm3
p.end
ralm
wr1
wr2
wr3
wr4
wr5
wr6
wr7
wr8
ALM1 None
Auxiliary Output 2
Assignment
sub2 Same as for control output 1. ALM2 None
Auxiliary Output 3
Assignment (E5AN/
E5EN only)
sub3 Same as for control output 1. ALM3 None
Character Select csel OFF, ON off, on ON None
Soak Time Unit t-u M: Minutes; H: Hours m, h MNone
Alarm SP Selection alsp SP-M: Ramp set point
SP: Set point
sp-m, sp SP-M None
Manual MV Limit
Enable
manl OFF, ON off, on ON None
PV Rate of Change
Calculation Period
pvrp 1 to 999 4 Sampling
period
Automatic Cooling
Coefficient Adjust-
ment
csca OFF, ON off, on OFF None
Heater Overcurrent
Use
ocu OFF, ON off, on ON None
Heater Overcurrent
Latch
ocl OFF, ON off, on OFF None
Heater Overcurrent
Hysteresis
och 0.1 to 50.0 0.1 A
PF Setting pf OFF: OFF
RUN: RUN
STOP: STOP
R-S: RUN/STOP
AT-2: 100% AT execute/cancel
AT-1: 40% AT execute/cancel
LAT: Alarm Latch Cancel
A-M: Auto/manual
PFDP: Monitor/setting item
off
run
stop
r-s
at-2
at-1
lat
a-m
pfdp
A-M None
Parameters Characters Setting (monitor) value Display Default Unit Set value
